PreServa 3200L Compact, modular walk-In chillers and freezers

Project Overview

HPCC

Rinac’s compact, modular step-in chillers and freezers can help make the right cold storage decisions for your business. As a leader in innovative cold chain solutions, Rinac has developed PreServa , the 3200 L energy-efficient, compact and adjustable standard cold storage room, a Walk In Chiller/ Step In Chiller and Walk In Freezer /Step In Freezer, to address the cold storage pain points across industries. Designed for maintaining a wide temperature range in high ambient conditions, PreServa is suitable for a variety of food items and goods with a shorter shelf-life.

PreServa not only helps you maintain the integrity and safety of the perishable or consumable products but are very easy to maintain and clean. Plus, they are eco-friendly!

Applications of Preserva

Salient Features

  • Energy-efficient and even suitable for high-ambient conditions.
  • Powder-coated galvanized iron (PCGI) or stainless steel lamination inside and outside
  • Quick assembling and dismantling in just three hours
  • Unitary refrigeration system
  • Suitable for the high ambient conditions
  • Equipped with the universal ‘cam lock Allen key’ and man-trap internal safety release lock
  • Door handle with key security lock
  • Insulated cap for cam lock system
  • Internal lighting
  • Four-tier adjustable shelving system
  • Microprocessor-based programmable electronic control
  • Single phase power (230 V)—standard 16A power point
  • Non-CFC refrigerant
  • Energy Efficient-25-30 Units
  • 3 Variance : 2 to 8 Deg, -2 to -5 Deg and -12 t0 -18 Deg
  • Food Grade Racking
  • Four tier adjustable shelving system for maximum utilisation of space

Benefits of PreServa

Advantages of PreServa

Advantages
  • Easier installation than any other product in the market
  • Affordable price for the capacity you buy for
  • Excellent service network
  • References and testimonials available from a variety of industries and application
  • Built with Rinac’s durable RPUF sandwich panel system, a market leading product

Technical Specifications

1. Cabinet Details

S. No Characteristics Unit Parameters
1.1 Cabinet Details
Length mm 2400
Width mm 1800
Height mm 2400
Net weight kg 970
1.2 Internal Dimensions – Chiller
Length mm 960
Width mm 1600
Height mm 2200
1.3 Internal Dimensions – Freezer
Length mm 1160
Width mm 1600
Height mm 2200
1.4 Storage Space
Chiller Room Volume litre 4600
Freezer Room Volume litre 4400
1.5 Cabinet Footprint
Length x Width mm 3200 x 1880
Clear Height mm 3000
1.6 Door – Panel Type with Auto Closure mm 600 x 1800

2. Shelving

Anodized Aluminium Frames with Polyethylene Shelves

  • Chiller: 2 Sets x 4 Shelves each
  • Freezer: 3 Sets x 4 Shelves each

3. Refrigeration System

Refrigerant R404A
Refrigeration Capacity 3 kW
Room Temp – Chiller / Freezer 4 to 8°C / -15 to -20°C
Type of Condensing Unit Air Cooled Split Type

4. Power Details

Cabinets are available in three laminations: PCGI / SS / PVC / SS finish

General Technical Specifications

Sl Characteristics Unit PreServa P PreServa C PreServa N
1 Cabinet Details
Length mm 1800 1800 1800
Width mm 1200 1200 1200
Height mm 2100 2100 2100
Net Weight kg 325 340 375
Insulation Thickness mm 60 60 100
2 Storage Space
Total Volume litre 3500 3500 3040
Shelf Capacity kg 200 200 150
3 Cabinet Footprint
Length mm 1880 1880 1880
Width mm 1800 1800 1800
4 Panel Door Size mm 600 x 1650 600 x 1650 600 x 1650
5 Refrigeration System
Temperature Range °C +2 to +8 -2 to -5 -12 to -18
Refrigerant R407C R407C R404A
Type of Condensing Unit Air Cooled Unitary Type Air Cooled Unitary Type Air Cooled Unitary Type
6 Power Details
Consumed Power kW 1.2 1.6 1.7
Connected Power kW 1.7 3.3 3.5
Power Supply 230V, 1Ph, 50Hz 230V, 1Ph, 50Hz 230V, 1Ph, 50Hz
