Cold rooms play a vital role in the cold-chain infrastructure, ensuring perishable goods remain fresh and safe. Rinac’s LiteCold Series is a cost-effective and energy-efficient modular cold room solution designed to meet small to medium storage requirements. It is customizable, easy to install, and ensures long-term preservation of products without compromising quality.
Prevents quality deterioration & extends product shelf life
Minimizes temperature fluctuations & enhances food safety
Reduces operational costs with energy-efficient technology
Quick installation with modular design & easy maintenance
Customizable options for different industries
Available for quick delivery from stock points
| Feature | Specification |
|---|---|
| Panel Thickness | 60, 100 mm |
| Temperature Range | -25°C to +70°C |
| Lamination Material | PCGI/PCGI |
| Panel Width | 1000 mm |
| Available Panel Lengths | 2500, 3000, 3500 mm |
| Color | White (RAL – 9002 finish) |
| Serration | Full line both sides |
| Floor Slab | PUF slabs |
| Door Size | 900 × 2000 mm (Flush Type) |
| Frame Heaters | Standard for low-temperature doors |
| Parameter | RLC-P25-01 | RLC-P30-03 | RLC-P40-03 | RLC-P50-03 | RLC-P60-03 |
|---|---|---|---|---|---|
| Refrigeration Capacity (kW) | 2.5 | 3 | 4 | 5 | 6 |
| Refrigerant | R407C | R407C | R407C | R407C | R407C |
| Power Supply (Ph/V/Hz) | 1/230/50 | 3/410/50 | 3/410/50 | 3/410/50 | 3/410/50 |
| Consumed Power (kW) | 1.5 | 2.1 | 2.7 | 3.2 | 3.6 |
| Parameter | RLC-N25-03 | RLC-N30-03 | RLC-N40-03 | RLC-N50-03 |
|---|---|---|---|---|
| Refrigeration Capacity (kW) | 2.5 | 3 | 4 | 5 |
| Refrigerant | R404A | R404A | R404A | R404A |
| Power Supply (Ph/V/Hz) | 3/410/50 | 3/410/50 | 3/410/50 | 3/410/50 |
Gain instant access to detailed product specifications, key features, and the benefits of partnering with Rinac
LiteCold is customizable, easy to install, and ensures long-term preservation of products without compromising quality.
